BD2425P50100AHF
RoHS
RoHS compliant
RoHS compliantPackage 0404 (1010 Metric)
Category RF/IF and RFID / Balun
Description
Signal Conditioning 2.4-2.5GHz 50/100 Ohm IL=.9dB
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.8448
≥1 USD $0.8448
≥10 USD $0.8272
≥100 USD $0.554048
≥500 USD $0.493152
≥1000 USD $0.451704
≥3000 USD $0.405293
Inventory: 7260
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0404 (1010 Metric)
Technical
Packaging Tape & Reel (TR)
Published 2006
Series Xinger?
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Additional Feature HEIGHT DIMENSION INCLUDES TERMINALS ALSO
Case Code (Metric) 1010
Case Code (Imperial) 0404
Physical Dimension 1.05mm X 1.05mm X 0.45mm
Impedance 100Ohm
Frequency Range 2.4GHz~2.5GHz
Insertion Loss (dB) 0.8 dB
Transformer Type RF TRANSFORMER
Insertion Loss (Max) 0.9dB
Return Loss-Min 15dB
Cut-off Frequency-Max 2500MHz
Cut-off Frequency-Min 2400MHz
Impedance - Unbalanced/Balanced 50 / 100Ohm
Phase Difference 6°
Dimensions
Height 0.45mm
Length 1.05mm
Width 1.05mm
Compliance
RoHS Status RoHS Compliant
