BD2425N50100AHF
RoHS
RoHS compliant
RoHS compliantPackage 0404 (1010 Metric)
Category RF/IF and RFID / Balun
Description
XFRMR BALUN RF 2400-2500MHZ 0404
PDF
/
Buying Options
Total Price: USD $0.76
Unit Price: USD $0.7568
≥1 USD $0.7568
≥10 USD $0.74008
≥100 USD $0.495616
≥500 USD $0.441232
≥1000 USD $0.404184
≥3000 USD $0.36263
Inventory: 8378
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 1.04mm
Height 0.56mm
Technical
Phase Difference 1°
Impedance - Unbalanced/Balanced 50 / 100Ohm
Cut-off Frequency-Max 2500MHz
Return Loss-Min 18dB
Insertion Loss (Max) 0.7dB
Turns Ratio - Primary:Secondary 1:1.41
Transformer Type RF TRANSFORMER
Insertion Loss (dB) 0.6 dB
Frequency Range 2.4GHz~2.5GHz
Impedance 100Ohm
Case Code (Imperial) 0404
Case Code (Metric) 1010
Depth 1.04mm
Min Operating Temperature -55°C
Max Operating Temperature 85°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Xinger?
Published 2008
Packaging Tape & Reel (TR)
Physical
Number of Pins 4
Package / Case 0404 (1010 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
