BD2425J50200AHF
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category RF/IF and RFID / Balun
Description
BALUN 2.4GHZ-2.5GHZ 50/200 0805
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.8448
≥1 USD $0.8448
≥10 USD $0.8272
≥100 USD $0.554048
≥500 USD $0.493152
≥1000 USD $0.451704
≥3000 USD $0.405293
Inventory: 1155
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 2.04mm
Height 0.71mm
Technical
Phase Difference 2°
Impedance - Unbalanced/Balanced 50 / 200Ohm
Return Loss-Min 12.2dB
Insertion Loss (Max) 0.6dB
Turns Ratio - Primary:Secondary 1:1.41
Transformer Type RF TRANSFORMER
Insertion Loss (dB) 0.8 dB
Frequency Range 2.4GHz~2.5GHz
Physical Dimension L2.04XB1.29XH0.71 (mm)
Frequency 2.5GHz
Depth 1.29mm
Min Operating Temperature -55°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Xinger?
Published 2010
Packaging Tape & Reel (TR)
Physical
Number of Pins 6
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
