BD2425J50100AHF
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category RF/IF and RFID / Balun
Description
RF Transformer 1:1.41 6Term. SMD
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.8448
≥1 USD $0.8448
≥10 USD $0.8272
≥100 USD $0.554048
≥500 USD $0.493152
≥1000 USD $0.451704
≥3000 USD $0.405293
Inventory: 1162
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Number of Pins 6
Technical
Packaging Tape & Reel (TR)
Published 2011
Series Xinger?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Subcategory Other Transformers
Power Rating 2W
Depth 1.29mm
Physical Dimension L2.04XB1.29XH0.71 (mm)
Application MATCHING
Frequency Range 2.4GHz~2.5GHz
Operating Frequency-Max 2500000kHz
Operating Frequency-Min 2400000kHz
Insertion Loss (dB) 0.75 dB
Transformer Type RF TRANSFORMER
Turns Ratio - Primary:Secondary 1:1.41
Insertion Loss (Max) 0.7dB
Return Loss-Min 14dB
Cut-off Frequency-Max 2500MHz
Cut-off Frequency-Min 2400MHz
Impedance - Unbalanced/Balanced 50 / 100Ohm
Phase Difference 5°
Secondary Impedance 50OhmS
Primary Impedance 100OhmS
Dimensions
Height 0.71mm
Length 2.04mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
