BD2040J50100AHF
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category RF/IF and RFID / Balun
Description
RF Transformer 1:1.41 6Term. SMD
PDF
/
Buying Options
Total Price: USD $1.15
Unit Price: USD $1.1528
≥1 USD $1.1528
≥10 USD $1.13256
≥100 USD $0.757856
≥500 USD $0.674784
≥1000 USD $0.6182
≥3000 USD $0.554611
Inventory: 1177
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Number of Pins 6
Technical
Packaging Tape & Reel (TR)
Published 2013
Series Xinger?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code 5A991.G
Max Operating Temperature 85°C
Min Operating Temperature -55°C
HTS Code 8517.70.00.00
Subcategory Other Transformers
Power Rating 2W
Depth 1.29mm
Frequency 4GHz
Physical Dimension 2.04mm x 1.29mm x 0.71mm
Application MATCHING
Frequency Range 2GHz~4GHz
Insertion Loss (dB) 1.1 dB
Transformer Type DATACOM TRANSFORMER
Turns Ratio - Primary:Secondary 1:1.41
Return Loss-Min 14dB
Impedance - Unbalanced/Balanced 50 / 100Ohm
Phase Difference 10°
Secondary Impedance 50OhmS
Primary Impedance 100OhmS
Dimensions
Height 0.71mm
Length 2.04mm
Compliance
RoHS Status RoHS Compliant
