BD1416N50100AHF
RoHS
RoHS compliant
RoHS compliantPackage 0404 (1010 Metric)
Category RF/IF and RFID / Balun
Description
RF Transformer 1:1.41 5Term. SMD
PDF
/
Buying Options
Total Price: USD $0.76
Unit Price: USD $0.7568
≥1 USD $0.7568
≥10 USD $0.74008
≥100 USD $0.495616
≥500 USD $0.441232
≥1000 USD $0.404184
≥3000 USD $0.36263
Inventory: 76038
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0404 (1010 Metric)
Number of Pins 5
Technical
Packaging Tape & Reel (TR)
Published 2012
Series Xinger?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Additional Feature HEIGHT DIMENSION INCLUDES TERMINALS ALSO
Packing Method TR, 7 INCH
Depth 1.04mm
Frequency Range 1.4GHz~1.6GHz
Insertion Loss (dB) 0.9 dB
Transformer Type RF TRANSFORMER
Turns Ratio - Primary:Secondary 1:1.41
Return Loss-Min -18dB
Cut-off Frequency-Max 1600MHz
Cut-off Frequency-Min 1400MHz
Impedance - Unbalanced/Balanced 50 / 100Ohm
Phase Difference 4°
Dimensions
Length 1.04mm
Compliance
RoHS Status RoHS Compliant
Alternative Model
