6450869-3 image
Favorite
6450869-3 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description Conn Power RCP 17Power/12Signal POS Press ST Thru-Hole 1Port
PDF
/
Inventory: 5832
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0

Dimensions

Plating Thickness 2.92μm

Technical

Contact Retention Without
Contact Layout, Typical 12 Signal, 17 Power
Number of Signal Positions 8
Number of Power Positions 17
Circuit Application Power
Contact Current Rating 42A
Sealable No
Connector Style Multi-Beam
ELV Compliant
Row Spacing 2.54 mm
Operating Supply Voltage 60V
Housing Color Black
Number of Contacts 29
Current Rating 42A
Number of Positions Loaded All
Orientation Vertical
Pitch 0.100 2.54mm
Gender Female
Number of Rows 4
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Number of Positions 29
Connector Type Receptacle, Female Sockets and Blade Sockets
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MULTI-BEAM XLE
Published 2011
Packaging Tray
Operating Temperature -40°C~125°C

Physical

PCB Mounting Orientation Vertical
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 25 Weeks
