6450832-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
MBXL R/A HEADER 6P+24S
PDF
/
Inventory: 8010
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 4.7μm
Technical
Contact Retention Without
Number of Signal Positions 24
Number of Power Positions 6
Circuit Application Power
Contact Current Rating 50A
Sealable No
ELV Compliant
Row Spacing 2.54 mm
Operating Supply Voltage 60V
Housing Color Black
Contact Gender MALE
Number of Contacts 30
Current Rating 50A
Orientation Right Angle
Pitch 6.35mm
Option GENERAL PURPOSE
Mixed Contacts YES
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 4
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Connector Type Pin
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2015
Physical
PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Mounting Type BOARD
Contact Plating Tin
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
