536504-8
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
High Speed / Modular Connectors Z PACK 144P
PDF
/
Inventory: 4611
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material PHOSPHOR BRONZE
Mount Through Hole
Mounting Type Through Hole
Housing Material Polymer
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 2011
Series Z-PACK
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type Header, Male Pins
Number of Positions 144
Color Natural
Number of Rows 4
Voltage - Rated 30V
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 300V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 144
Number of Positions Loaded All
Reach Compliance Code unknown
Number of Conductors ONE
Reference Standard UL, CSA
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 2.83 inch
Number Of PCB Rows 4
PCB Contact Pattern RECTANGULAR
Body Breadth 0.622 inch
Body Depth 0.669 inch
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Body/Shell Style RECEPTACLE
Polarization Key POLARIZED HOUSING
Connector Style Futurebus
PCB Contact Row Spacing 2.0066 mm
Durability 250 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max .695 N
Withdrawl Force-Min .1112 N
Mating Contact Row Spacing 0.079 inch
Dimensions
Plating Thickness FLASH inch
Length - Termination 0.167 inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
