532840-1
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Specialized Connector
PDF
/
Inventory: 1608
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Plastic
Technical
Operating Temperature -65°C~125°C
Packaging Tube
Published 2009
Series HDI (High Density Interconnect)
Feature Mating Guide
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Female Sockets
Number of Positions 516
Max Operating Temperature 125°C
Min Operating Temperature -65°C
Color Natural
Number of Rows 4
Gender Receptacle
Pitch 0.100 2.54mm
Number of Positions Loaded All
Contact Finish Gold
Number of Contacts 516
Connector Style High Density (HDC, HDI, HPC)
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
