532448-8
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
High Speed / Modular Connectors HDI PCB PIN 4RW 220P
PDF
/
Inventory: 7890
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Material Bronze
Contact Plating Tin, Gold
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
PCB Mount Retention With
Underplate Material Nickel
Technical
Operating Temperature -65°C~125°C
Packaging Tube
Published 1998
Series HDI (High Density Interconnect)
Feature Mating Guide
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Header, Male Pins
Number of Positions 220
Color Black
Number of Rows 4
Gender Male
Additional Feature AMP-HDI
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 220
Orientation Vertical
Number of Positions Loaded All
Contact Finish Gold
Housing Color Black, Brown
Lead Length 6.35mm
Insulation Resistance 4MOhm
Row Spacing 2.54 mm
ELV Non-Compliant
Connector Style High Density (HDC, HDI, HPC)
Contact Current Rating 3A
Circuit Application Signal
Mating Post Length 5.334mm
Mating Alignment Without
Stackable No
Dimensions
Height 11.7348mm
Length 158.75mm
Contact Finish Thickness 30.0μin 0.76μm
Contact Finish Thickness - Mating 762 nm
Length - Tail 6.35mm
PCB Thickness 2.13mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
