5223513-8
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Hard Metric Connectors 2MMFB IS ASY 168 SIG HDR SL
PDF
/
Inventory: 3840
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Material Bronze
Contact Plating Gold, Tin
Mount Edge, Through Hole
Mounting Type Board Edge, Through Hole, Right Angle
Housing Material Polymer
PCB Mounting Orientation Right Angle
PCB Mount Retention With
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 1999
Series Z-PACK
Feature Board Guide
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Header, Male Pins
Color Natural
Number of Rows 4
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 168
Orientation Right Angle
Number of Positions Loaded All
Number of Conductors ONE
Reference Standard UL, CSA
Contact Finish Gold
Voltage - Rated AC 30V
Reliability COMMERCIAL
Number Of PCB Rows 4
PCB Contact Pattern RECTANGULAR
Body Breadth 0.622 inch
Lead Length 2.73mm
Body Depth 1.26 inch
Operating Supply Voltage 30V
Contact Style SQ PIN-SKT
Insulation Resistance 5GOhm
Row Spacing 2 mm
Body/Shell Style PLUG
ELV Compliant
Dielectric Withstanding Voltage 1000VAC V
Connector Style Futurebus
Durability 100 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max .1112 N
Withdrawl Force-Min .695 N
Sealable No
Contact Current Rating 3A
Circuit Application Signal
Number of Signal Positions 168
Mating Post Length 5mm
Dimensions
Height 11.180064mm
Length 83.88mm
Width 16mm
Plating Thickness 3.81μm
Contact Finish Thickness - Mating 80 nm
Length - Tail 2.73mm
PCB Thickness 1.3mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
