5120795-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Hard Metric Connectors ZP HS3 DB 10R REC 050P RT PD P
PDF
/
Inventory: 9565
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 33 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Polyester
PCB Mounting Orientation Right Angle
Technical
Operating Temperature -65°C~105°C
Packaging Tube
Published 2008
Series Z-PACK HS3
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Receptacle, Female Sockets
Number of Rows 10
Gender Receptacle
Voltage - Rated 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.098 2.50mm
Total Number of Contacts 50
Orientation Right Angle
Number of Positions Loaded All
Current Rating 1.15A
Contact Finish Gold
Shrouding Unshrouded
Housing Color Black
Lead Length 2.2606mm
Operating Supply Voltage 250V
Row Spacing 2.0066 mm
ELV Compliant
Max Current Rating 1.15A
Connector Style Dual Beam, Left Side
Contact Current Rating 1.15A
Circuit Application Signal
Number of Signal Positions 50
Hole Diameter 50 μm
Number of Columns 5
Connector Usage Backplane
Mating Alignment With
Preloaded Yes
Differential Signaling No
Dimensions
Height 11.95mm
Length 22.86mm
Width 28.67mm
Contact Finish Thickness 30.0μin 0.76μm
Length - Tail 2.1082mm
PCB Thickness 1.4mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
