3-5223611-5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Hard Metric Connectors 2MMFB ASY 048 SIG HDR EN SEQ
PDF
/
Inventory: 6239
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Contact Material Bronze
Contact Plating Gold, Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polymer
PCB Mounting Orientation Vertical
PCB Mount Retention With
PCB Mount Alignment Without
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 1999
Series Z-PACK
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Header, Male Pins
Number of Positions 48
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Natural
Number of Rows 4
Voltage - Rated 30V
Pitch 0.079 2.00mm
Orientation Vertical
Number of Positions Loaded All
Contact Finish Gold
Voltage - Rated AC 30V
Number of Contacts 48
Housing Color Natural
Operating Supply Voltage 30V
Insulation Resistance 5GOhm
Row Spacing 2 mm
ELV Compliant
Plating Gold
Connector Style Futurebus
Sealable No
Contact Current Rating 3A
Circuit Application Signal
Number of Signal Positions 48
Mating Alignment With
Stackable No
Dimensions
Height 17mm
Length 23.88mm
Plating Thickness 60 nm
Contact Finish Thickness - Mating 50 nm
PCB Thickness 1.27mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
