2132721-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
IMP100O,R,RA6P12C,LG,39
PDF
/
Inventory: 949
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
PCB Thickness 1mm
Length - Tail 1.2mm
Plating Thickness 1.52μm
Width 37.3mm
Length 32.4104mm
Height 25.4mm
Technical
Number of Ground Positions 72
Differential Pairs per Column 6
Number of Pairs 72
Differential Signaling Yes
Make First / Break Last No
Stackable No
Mating Alignment With
Number of Columns 12
Hole Diameter 381 μm
Number of Signal Positions 144
Data Rate 25 Gbps
Circuit Application Signal
Contact Current Rating 750mA
Sealable No
Impedance 100Ohm
Max Current Rating 750mA
ELV Compliant
Row Spacing 1.35 mm
Contact Style Press-Fit
Operating Supply Voltage 30V
Housing Color Black
Number of Contacts 216
Shrouding Unshrouded
Current Rating 750mA
Orientation Right Angle
Pitch 1.905mm
Number of Rows 18
Min Operating Temperature -67°C
Max Operating Temperature 185°C
Number of Positions 216
Connector Type Receptacle
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2011
Packaging Box
Physical
Underplate Material Nickel
PCB Mounting Orientation Right Angle
Housing Material Polymer
Contact Plating Gold, Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 17 Weeks
