2007832-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
High Speed / Modular Connectors
PDF
/
Inventory: 937
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Plating Gold, Tin
Mounting Type Through Hole
Housing Material Polymer
PCB Mounting Orientation Vertical
Underplate Material Nickel
Technical
Operating Temperature -55°C~ 85°C
Packaging Bulk
Published 2013
Series Impact
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Header, Male Pins
Number of Positions 192
Max Operating Temperature 185°C
Min Operating Temperature -67°C
Color Black
Number of Rows 12
Voltage - Rated 30V
Voltage - Rated DC 30V
Current Rating (Amps) 0.75A
Pitch 0.075 1.91mm
Orientation Vertical
Depth 20.8mm
Number of Positions Loaded All
Current Rating 750mA
Contact Finish Gold
Shrouding Partially Shrouded
Number of Contacts 192
Housing Color Black
Operating Supply Voltage 30V
Contact Style Press-Fit
Row Spacing 1.35 mm
ELV Compliant
Max Voltage Rating (AC) 120V
Max Current Rating 750mA
Impedance 100Ohm
Connector Style Impact
Sealable No
Contact Current Rating 750mA
Circuit Application Signal
Data Rate 25 Gbps
Number of Signal Positions 128
Hole Diameter 457.2 μm
Contact Layout, Typical 128 Signal, 64 Ground
Number of Columns 16
Mating Alignment With
Stackable No
Make First / Break Last No
Differential Signaling Yes
Number of Pairs 64
Differential Pairs per Column 4
Number of Ground Positions 64
Dimensions
Height 11.95mm
Length 30.3mm
Width 20.8026mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 760 nm
Length - Tail 1.4mm
PCB Thickness 1mm
Stack Height 11.95mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
