2-6450832-5 image
Favorite
2-6450832-5 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description CONN HDR MULT-BEAM 31POS EDGE MT
PDF
/
Inventory: 7620
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)

Physical

Contact Material Copper
Contact Plating Tin
Mounting Type Board Edge, Through Hole, Right Angle
Housing Material Thermoplastic
PCB Mounting Orientation Right Angle

Technical

Packaging Tray
Published 2015
Series MULTI-BEAM XLE
Feature Board Lock, Mating Guide
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header, Male Pins and Blades
Number of Positions 31
Max Operating Temperature 125°C
Contact Retention Without
Contact Layout, Typical 24 Signal, 7 Power
Number of Signal Positions 24
Number of Power Positions 7
Circuit Application Power
Contact Current Rating 50A
Sealable No
Connector Style Multi-Beam
ELV Compliant
Row Spacing 2.54 mm
Operating Supply Voltage 60V
Housing Color Black
Number of Contacts 31
Contact Finish Gold
Current Rating 50A
Number of Positions Loaded All
Orientation Right Angle
Pitch 0.100 2.54mm
Number of Rows 4
Min Operating Temperature -40°C

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0

Dimensions

Plating Thickness 3.43μm
Contact Finish Thickness 30.0μin 0.76μm
