2-6450541-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Conn Power RCP 32Signal POS Press ST Thru-Hole 1Port
PDF
/
Inventory: 4104
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Contact Material Copper
Contact Plating Tin
Mount Through Hole
Housing Material Thermoplastic
PCB Mounting Orientation Vertical
Technical
Published 2012
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Socket
Number of Positions 32
Max Operating Temperature 105°C
Min Operating Temperature -20°C
Number of Rows 4
Pitch 2.54mm
Orientation Vertical
Current Rating 42A
Number of Contacts 32
Housing Color Black
Operating Supply Voltage 60V
Row Spacing 2.54 mm
ELV Compliant
Sealable No
Contact Current Rating 42A
Circuit Application Power
Number of Signal Positions 32
Contact Retention Without
Dimensions
Plating Thickness 3.43μm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
