1410217-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Conn Daughter Card PL 1.8mm Solder RA Thru-Hole
PDF
/
Buying Options
Total Price: USD $111.07
Unit Price: USD $111.073966
≥1 USD $111.073966
≥200 USD $42.984346
≥500 USD $41.473198
≥1000 USD $40.727471
Inventory: 957
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 30.48mm
Technical
Connector Usage Daughtercard
Number of Columns 16
Contact Layout, Typical 160 Signal, 80 Ground
Data Rate 3.12 Gbps
Contact Current Rating 1A
Connector Style MULTIGIG, Full, Right End
ELV Non-Compliant
Row Spacing 36.83 mm
Housing Color Black
Contact Finish Gold
Number of Positions Loaded All
Orientation Right Angle
Pitch 0.071 1.80mm
Voltage - Rated 50V
Number of Rows 15
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 240
Connector Type Plug, Male Blades
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MultiGig RT1
Published 2005
Packaging Tube
Operating Temperature -55°C~105°C
Physical
PCB Mounting Orientation Right Angle
Housing Material Polymer
Mounting Type Board Edge, Through Hole, Right Angle
Mount Edge, Through Hole
Contact Plating Gold
Contact Material Bronze
Supply Chain
Factory Lead Time 14 Weeks
