1375798-5 image
Favorite
1375798-5 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description AMPMODU RoHS Compliant 2008 Straight Connector Non-Stackthrough, Keyed (PC/104) UL94V-0 -55C~105C 3A 15.0muin 0.38mum
PDF
/
Inventory: 2280
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 28 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Contact Material Bronze
Mount Press Fit, Through Hole
Mounting Type Through Hole
Housing Material Nylon

Technical

Operating Temperature -55°C~105°C
Packaging Bulk
Published 2008
Series AMPMODU
Feature Screwlocks (2)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Non-Stackthrough, Keyed (PC/104)
Number of Positions 120
Color Black
Number of Rows 4
Gender Receptacle
Additional Feature POLARIZED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 119
Orientation Straight
Number of Positions Loaded 119
Current Rating 3A
Contact Finish Gold
Approval Agency cULus
Lead Length 2.8448mm
Insulation Resistance 1GOhm
ELV Compliant
Connector Style PC/104 Plus
Keyed Yes

Dimensions

Contact Finish Thickness 15.0μin 0.38μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
