1375798-1
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
PC / 104 Connectors 120P PC/104-PLUS 2 standoffs unkeyed
PDF
/
Inventory: 3480
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Contact Material Bronze
Mount Press Fit, Through Hole
Mounting Type Through Hole
Housing Material Nylon
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2008
Series AMPMODU
Feature Screwlocks (2)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type Non-Stackthrough, Unkeyed (PC/104)
Number of Positions 120
Color Black
Number of Rows 4
Gender Receptacle
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 120
Orientation Straight
Number of Positions Loaded All
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 4
Lead Pitch 2mm
PCB Contact Pattern RECTANGULAR
Body Breadth 0.315 inch
Lead Length 2.8448mm
Body Depth 0.368 inch
Rated Current (Signal) 2A
Contact Style SQ PIN-SKT
Contact Resistance 10mOhm
Insulation Resistance 1GOhm
ELV Non-Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 500VAC V
Connector Style PC/104 Plus
PCB Contact Row Spacing 2.0066 mm
Durability 50 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max 1.251 N
Withdrawl Force-Min .6672 N
Mating Contact Row Spacing 0.079 inch
Keyed No
Dimensions
Height 9.35mm
Length 60.2mm
Width 8mm
Contact Finish Thickness 15.0μin 0.38μm
Plating Thickness 15μin
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
