1-5532448-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
HDI (High Density Interconnect) RoHS Compliant 2009 GENERAL PURPOSE Connector Header, Male Pins UL94V-0 -65C~125C 30.0muin 0.76mum
PDF
/
Inventory: 7521
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Technical
Connector Style High Density (HDC, HDI, HPC)
ELV Compliant
Housing Color Brown
Contact Finish Gold
Number of Positions Loaded All
Total Number of Contacts 300
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Male
Number of Rows 4
Color Black
Number of Positions 300
Connector Type Header, Male Pins
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Mating Guide
Series HDI (High Density Interconnect)
Published 2009
Packaging Tube
Operating Temperature -65°C~125°C
Physical
Mounting Type Through Hole
Mount Through Hole
Contact Material Bronze
