6450552-2
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
WITH GUIDES Specialized Connector
PDF
/
Inventory: 8221
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length - Termination 0.135 inch
Plating Thickness 30μin
Technical
Contact Arrangement S92P2
Durability 250 Cycles
Dielectric Withstanding Voltage 2500VDC V
Termination Type PRESS FIT
Body/Shell Style RECEPTACLE
Insulation Resistance 500000000Ohm
Contact Resistance 20mOhm
Contact Style HYBRID
Body Depth 0.5 inch
Operating Temperature (Min) -20°C
Contact Gender FEMALE
Body Breadth 0.47 inch
Operating Temperature (Max) 105°C
Body Length or Diameter 3.45 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Total Number of Contacts 94
Mixed Contacts YES
Contact Finish - Mating AU
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature WITH GUIDES
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Physical
Board Mounting Option SPLIT BOARD LOCK
Mounting Style STRAIGHT
Mounting Option 1 LOCKING
Insulation Material GLASS FILLED THERMOPLASTIC
Mounting Type BOARD
Contact Material COPPER ALLOY
