536603-1
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
CONN HEADER VERT 2MM 8POS 30AU
PDF
/
Inventory: 7971
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Plating Thickness FLASH inch
Length 11.83mm
Technical
Make First / Break Last No
Mating Contact Row Spacing 0.079 inch
Insertion Force-Max 2.3352 N
Contact Pattern RECTANGULAR
Durability 250 Cycles
PCB Contact Row Spacing 2.0066 mm
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 30V
ELV Non-Compliant
Body/Shell Style RECEPTACLE
Contact Style BLADE PIN-SKT
Rated Current (Signal) 3A
Body Breadth 0.622 inch
PCB Contact Pattern RECTANGULAR
Lead Pitch 2mm
Number Of PCB Rows 4
Reliability COMMERCIAL
Voltage - Rated AC 30V
Reference Standard UL, CSA
Number of Conductors ONE
Depth 15.8mm
Total Number of Contacts 8
Pitch 2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Additional Feature Z-PACK
Voltage - Rated 30V
Gender Male
Number of Rows 4
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 8
Connector Type Header, Pin, Plug
Termination Press-Fit
Pbfree Code no
Physical
PCB Mounting Orientation Vertical
Housing Material Polymer
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
