RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description Specialized Connector
PDF
/
Inventory: 985
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Technical

Make First / Break Last Yes
Mating Post Length 5.75mm
Max Voltage Rating (AC) 30V
ELV Compliant
Lead Length 13.6mm
Contact Gender MALE
Voltage - Rated AC 30V
Total Number of Contacts 120
Pitch 2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Voltage - Rated 30V
Number of Rows 5
Color Natural
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 120
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Press-Fit

Physical

PCB Mounting Orientation Vertical
Housing Material Polymer
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
