1715749807
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
CONN HDR IMPACT 96POS EDGE MNT
PDF
/
Inventory: 8142
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
Length 25.2mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Technical
Number of Columns 8
Contact Layout, Typical 32 Differential Pairs
Withdrawl Force-Min .14734 N
Insertion Force-Max .3336 N
Contact Pattern RECTANGULAR
Durability 200 Cycles
PCB Contact Row Spacing 1.3462 mm
Connector Style Impact, Guide Bottom
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Insulation Resistance 1000000000Ohm
Contact Resistance 10mOhm
Rated Current (Signal) 0.75A
Body Depth 1.673 inch
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 12
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Number of Positions Loaded All
Orientation Right Angle
Total Number of Contacts 96
Pitch 1.9mm
Subcategory Headers and Edge Type Connectors
Voltage - Rated 30V
Number of Rows 12
Color Black
Number of Positions 96
Connector Type Header, Male Pins
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide
JESD-609 Code e3
Series Impact 171574
Published 2013
Packaging Tray
Operating Temperature -55°C~85°C
Physical
Housing Material Polymer
Mounting Type Board Edge, Through Hole, Right Angle
Mount Edge, Through Hole
Contact Plating Gold, Tin
Supply Chain
Factory Lead Time 13 Weeks
