1713203022
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Specialized Connector
PDF
/
Buying Options
Total Price: USD $24.08
Unit Price: USD $24.0768
≥1 USD $24.0768
≥10 USD $23.188
≥100 USD $22.7392
≥500 USD $22.2992
Inventory: 344
Minimum: 1
-
+
Technical Details
Technical
Dielectric Withstanding Voltage 500VAC V
Connector Style Impel, Guide Left
Durability 200 Cycles
Contact Pattern RECTANGULAR
Withdrawl Force-Min .139 N
Contact Layout, Typical 48 Differential Pairs
Number of Columns 12
Connector Usage Coplanar, Daughtercard
Polarization Key POLARIZED HOUSING
Number of Circuits 144
Mating Contact Pitch 0.075 inch
Insulation Resistance 1000000000Ohm
Contact Resistance 10mOhm
Rated Current (Signal) 0.75A
Body Depth 1.331 inch
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 12
Body Length or Diameter 1.22 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Number of Positions Loaded All
Terminal Pitch 1.905mm
Orientation Right Angle
Total Number of Contacts 144
Subcategory Headers and Edge Type Connectors
Number of Rows 8
Color Black
Number of Positions 96
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Shielded
Series Impel 171320
Published 2014
Packaging Tray
Operating Temperature -40°C~105°C
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Length - Termination 0.051 inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Physical
Mounting Option 1 LOCKING
Insulation Material GLASS FILLED LIQUID CRYSTAL POLYMER
Mounting Type Through Hole, Right Angle
Supply Chain
Factory Lead Time 15 Weeks
