1705301020
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Specialized Connector
PDF
/
Buying Options
Total Price: USD $16.26
Unit Price: USD $16.264549
≥1 USD $16.264549
≥10 USD $15.343916
≥100 USD $14.475395
≥500 USD $13.656033
≥1000 USD $12.883054
Inventory: 2245
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length - Termination 0.047 inch
Contact Finish Thickness 30.0μin 0.76μm
Technical
Number of Columns 10
Contact Layout, Typical 30 Differential Pairs
Withdrawl Force-Min .0834 N
Durability 200 Cycles
Connector Style Impact
Dielectric Withstanding Voltage 250VAC V
Mating Contact Pitch 0.075 inch
Rated Current (Signal) 0.75A
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Number of Positions Loaded All
Orientation Right Angle
Total Number of Contacts 90
Subcategory Headers and Edge Type Connectors
Voltage - Rated 30V
Number of Rows 9
Color Gray
Number of Positions 90
Connector Type Receptacle, Female Sockets
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Impact 170530
Published 2013
Packaging Tray
Operating Temperature -55°C~85°C
Physical
Insulation Material THERMOPLASTIC
Mounting Type Board Edge, Through Hole, Right Angle
Mount Edge, Through Hole
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 13 Weeks
