1705251108
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
CONN HEADER IMPACT 90POS PCB
PDF
/
Inventory: 1461
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length - Termination 0.055 inch
Contact Finish Thickness 30.0μin 0.76μm
Technical
Number of Columns 10
Contact Layout, Typical 30 Differential Pairs
Withdrawl Force-Min .0834 N
Durability 200 Cycles
Connector Style Impact
Dielectric Withstanding Voltage 250VAC V
Mating Contact Pitch 0.075 inch
Rated Current (Signal) 0.75A
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Number of Positions Loaded All
Total Number of Contacts 90
Subcategory Headers and Edge Type Connectors
Voltage - Rated 30V
Number of Rows 9
Color Gray
Number of Positions 90
Connector Type Header, Male Pins
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Impact 170525
Published 2015
Packaging Tray
Operating Temperature -55°C~85°C
Physical
Mounting Option 1 LOCKING
Insulation Material GLASS FILLED LIQUID CRYSTAL POLYMER
Mounting Type Through Hole
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 20 Weeks
