1704151122
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Specialized Connector
PDF
/
Buying Options
Total Price: USD $13.73
Unit Price: USD $13.73286
≥1 USD $13.73286
≥10 USD $12.955531
≥100 USD $12.222196
≥500 USD $11.530374
≥1000 USD $10.877704
Inventory: 9100
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material NOT SPECIFIED
Mounting Type Through Hole
Insulation Material GLASS FILLED LIQUID CRYSTAL POLYMER
Mounting Option 1 LOCKING
Technical
Operating Temperature -55°C~85°C
Packaging Tray
Published 2012
Series Impact 170415
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Receptacle, Female Sockets
Number of Positions 90
Color Black
Number of Rows 9
Voltage - Rated 30V
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 90
Number of Positions Loaded All
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 9
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.606 inch
Rated Current (Signal) 0.75A
Contact Style SQ PIN-SKT
Mating Contact Pitch 0.075 inch
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 500VAC V
Connector Style Impact
Durability 200 Cycles
Contact Pattern RECTANGULAR
Contact Layout, Typical 30 Differential Pairs
Number of Columns 10
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Length - Termination 0.047 inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
