1703401024
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Specialized Connector
PDF
/
Inventory: 2056
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length - Termination 0.047 inch
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
Technical
Number of Columns 14
Contact Layout, Typical 56 Differential Pairs
Withdrawl Force-Min .0834 N
Insertion Force-Max .3892 N
Durability 200 Cycles
Connector Style Impact
Dielectric Withstanding Voltage 250VAC V
Mating Contact Pitch 0.075 inch
Insulation Resistance 1000000000Ohm
Contact Resistance 10mOhm
Rated Current (Signal) 0.75A
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Terminal Pitch 1.905mm
Total Number of Contacts 168
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Voltage - Rated 30V
Number of Rows 12
Color Gray
Number of Positions 168
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Impact 170340
Published 2013
Packaging Tray
Operating Temperature -55°C~85°C
Physical
Mounting Option 1 LOCKING
Insulation Material THERMOPLASTIC
Mounting Type Board Edge, Through Hole, Right Angle
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 8 Weeks
