1703353106
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Impact 170335 ROHS3Compliant COMMERCIAL UL Connector Header, Male Pins 200Cycles -55C~85C 0.75A 30.0muin 0.76mum
PDF
/
Buying Options
Total Price: USD $13.61
Unit Price: USD $13.6136
≥1 USD $13.6136
≥10 USD $13.1032
≥100 USD $12.8568
≥500 USD $12.6104
Inventory: 243
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Contact Material NOT SPECIFIED
Mounting Type Through Hole
Insulation Material THERMOPLASTIC
Mounting Option 1 LOCKING
Technical
Operating Temperature -55°C~85°C
Packaging Tray
Published 2013
Series Impact 170335
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type Header, Male Pins
Number of Positions 120
Color Gray
Number of Rows 12
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Total Number of Contacts 120
Terminal Pitch 1.905mm
Number of Positions Loaded All
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 12
PCB Contact Pattern RECTANGULAR
Rated Current (Signal) 0.75A
Contact Style RND PIN-SKT
Mating Contact Pitch 0.075 inch
Connector Style Impact, Guide Left
PCB Contact Row Spacing 1.3462 mm
Durability 200 Cycles
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.053 inch
Contact Layout, Typical 40 Differential Pairs
Number of Columns 10
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Length - Termination 0.055 inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
