1703351227
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
CONN HEADER IMPACT 144POS PCB
PDF
/
Buying Options
Total Price: USD $14.63
Unit Price: USD $14.6344
≥1 USD $14.6344
≥10 USD $14.0888
≥100 USD $13.8248
≥500 USD $13.552
≥1000 USD $12.672
≥3000 USD $11.836
Inventory: 12162
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length - Termination 0.055 inch
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
Technical
Contact Layout, Typical 48 Differential Pairs
Mating Contact Row Spacing 0.053 inch
Contact Pattern RECTANGULAR
Durability 200 Cycles
PCB Contact Row Spacing 1.3462 mm
Connector Style Impact
Mating Contact Pitch 0.075 inch
Insulation Resistance 1000000000Ohm
Contact Resistance 10mOhm
Contact Style RND PIN-SKT
Rated Current (Signal) 0.75A
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 12
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Number of Positions Loaded All
Terminal Pitch 1.905mm
Total Number of Contacts 144
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 12
Color Gray
Number of Positions 144
Connector Type Header, Male Pins
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Impact 170335
Published 2013
Packaging Tray
Operating Temperature -55°C~85°C
Physical
Mounting Option 1 LOCKING
Insulation Material THERMOPLASTIC
Mounting Type Through Hole
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 15 Weeks
