1703351107
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
CONN HEADER IMPACT 120POS PCB
PDF
/
Inventory: 6578
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Contact Material NOT SPECIFIED
Mounting Type Through Hole
Insulation Material THERMOPLASTIC
Mounting Option 1 LOCKING
Technical
Operating Temperature -55°C~85°C
Packaging Tray
Published 2013
Series Impact 170335
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type Header, Male Pins
Number of Positions 120
Color Gray
Number of Rows 12
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Total Number of Contacts 120
Terminal Pitch 1.905mm
Number of Positions Loaded All
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 12
PCB Contact Pattern RECTANGULAR
Rated Current (Signal) 0.75A
Contact Style RND PIN-SKT
Mating Contact Pitch 0.075 inch
Connector Style Impact
PCB Contact Row Spacing 1.3462 mm
Durability 200 Cycles
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.053 inch
Contact Layout, Typical 24 Differential Pairs
Number of Columns 10
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Length - Termination 0.055 inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
