0769851128
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Specialized Connector
PDF
/
Inventory: 3166
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length - Termination 0.055 inch
Contact Finish Thickness 30.0μin 0.76μm
Technical
Number of Columns 10
Contact Layout, Typical 50 Differential Pairs
Withdrawl Force-Min .14734 N
Insertion Force-Max .3336 N
Durability 200 Cycles
Connector Style Impact
Dielectric Withstanding Voltage 500VAC V
Mating Contact Pitch 0.085 inch
Rated Current (Signal) 0.75A
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Number of Positions Loaded All
Total Number of Contacts 150
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Voltage - Rated 30V
Number of Rows 15
Color Black
Number of Positions 150
Connector Type Header, Male Pins
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Impact 76985
Packaging Tray
Operating Temperature -55°C~85°C
Physical
Mounting Option 2 LOCKING
Mounting Option 1 LOCKING
Insulation Material THERMOPLASTIC
Mounting Type Through Hole
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 13 Weeks
