0768457805
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Specialized Connector
PDF
/
Inventory: 7797
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material NOT SPECIFIED
Mounting Type Through Hole
Insulation Material THERMOPLASTIC
Mounting Option 1 GUIDE PIN
Mounting Option 2 LOCKING
Technical
Operating Temperature -55°C~85°C
Packaging Tray
Series Impact 76845
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type Header, Male Pins
Number of Positions 96
Color Black
Number of Rows 12
Voltage - Rated 30V
Subcategory Headers and Edge Type Connectors
Total Number of Contacts 96
Terminal Pitch 2.159mm
Number of Positions Loaded All
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 12
Rated Current (Signal) 0.75A
Contact Resistance 10mOhm
Insulation Resistance 1000000000Ohm
Dielectric Withstanding Voltage 500VAC V
Connector Style Impact, Guide Left
Durability 200 Cycles
Insertion Force-Max .3336 N
Withdrawl Force-Min .14734 N
Contact Layout, Typical 32 Differential Pairs
Number of Columns 8
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Length - Termination 0.055 inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
