0766805006

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description Specialized Connector
PDF
/
Inventory: 10015
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Length - Termination 0.051 inch
Contact Finish Thickness 30.0μin 0.76μm

Technical

Number of Columns 6
Durability 200 Cycles
Connector Style I-Trac, Guide Right
Dielectric Withstanding Voltage 750VAC V
Mating Contact Pitch 0.145 inch
Insulation Resistance 1000000000Ohm
Contact Resistance 10mOhm
Rated Current (Signal) 1A
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Number of Positions Loaded All
Terminal Pitch 3.7084mm
Total Number of Contacts 132
Subcategory Headers and Edge Type Connectors
Number of Rows 11
Color Black
Number of Positions 132
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
Series GbX I-Trac 76680
Packaging Tray
Operating Temperature -55°C~80°C

Physical

Mounting Option 2 LOCKING
Mounting Option 1 GUIDE SLOT
Insulation Material THERMOPLASTIC
Mounting Type Board Edge, Through Hole, Right Angle
Contact Material NOT SPECIFIED

Supply Chain

Factory Lead Time 6 Weeks
