0766801006
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Specialized Connector
PDF
/
Inventory: 8809
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material NOT SPECIFIED
Mounting Type Board Edge, Through Hole, Right Angle
Insulation Material THERMOPLASTIC
Mounting Option 1 LOCKING
Technical
Operating Temperature -55°C~80°C
Packaging Tray
Series GbX I-Trac 76680
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 132
Color Black
Number of Rows 11
Subcategory Headers and Edge Type Connectors
Total Number of Contacts 132
Number of Positions Loaded All
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Rated Current (Signal) 1A
Contact Resistance 10mOhm
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.145 inch
Dielectric Withstanding Voltage 750VAC V
Connector Style I-Trac
Durability 200 Cycles
Number of Columns 6
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Length - Termination 0.051 inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
