0765609107

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description Conn Backplane HDR 180 POS 1.9mm Press Fit RA Thru-Hole Impact? Tray
PDF
/
Inventory: 5911
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
Length 26.6mm

Technical

Number of Columns 10
Contact Layout, Typical 60 Differential Pairs
Withdrawl Force-Min .14734 N
Insertion Force-Max .3336 N
Durability 200 Cycles
Connector Style Impact, Guide Right
Dielectric Withstanding Voltage 500VAC V
Max Voltage Rating (AC) 30V
Rated Current (Signal) 0.75A
Reliability COMMERCIAL
Contact Finish Gold
Number of Conductors ONE
Number of Positions Loaded All
Depth 58.5mm
Orientation Right Angle
Total Number of Contacts 180
Pitch 0.053 1.35mm
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 18
Color Black
Number of Positions 180
Connector Type Header, Male Pins
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Impact 76560
Packaging Tray
Operating Temperature -55°C~85°C

Physical

Housing Material Polymer
Mounting Type Board Edge, Through Hole, Right Angle
Mount Edge, Through Hole
Contact Plating Gold, Tin
Contact Material NOT SPECIFIED

Supply Chain

Factory Lead Time 13 Weeks
