0765603108
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Impact 76560 ROHS3Compliant COMMERCIAL Gold Connector Header, Male Pins 200Cycles .3336N -55C~85C 0.75A
PDF
/
Inventory: 5791
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material NOT SPECIFIED
Mounting Type Board Edge, Through Hole, Right Angle
Insulation Material THERMOPLASTIC
Mounting Option 1 GUIDE PIN
Mounting Option 2 LOCKING
Technical
Operating Temperature -55°C~85°C
Packaging Tray
Series Impact 76560
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type Header, Male Pins
Number of Positions 180
Color Black
Number of Rows 18
Voltage - Rated 30V
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Pitch 0.053 1.35mm
Total Number of Contacts 180
Number of Positions Loaded All
Number of Conductors ONE
Contact Finish Gold
Reliability COMMERCIAL
Rated Current (Signal) 0.75A
Dielectric Withstanding Voltage 500VAC V
Connector Style Impact, Guide Left
Durability 200 Cycles
Insertion Force-Max .3336 N
Withdrawl Force-Min .14734 N
Contact Layout, Typical 60 Differential Pairs
Number of Columns 10
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Length - Termination 0.047 inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
