0765005607

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description Specialized Connector
PDF
/
Inventory: 5343
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness 30.0μin 0.76μm

Technical

Number of Columns 16
Contact Layout, Typical 64 Differential Pairs
Connector Style Impact, Guide Right
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Number of Positions Loaded All
Terminal Pitch 1.9mm
Total Number of Contacts 192
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.69.40.40
Voltage - Rated 30V
Number of Rows 12
Color Black
Number of Positions 192
Connector Type Header, Male Pins
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
JESD-609 Code e3
Series Impact 76500
Packaging Tray
Operating Temperature -55°C~85°C

Physical

Mounting Type Board Edge, Through Hole, Right Angle
Contact Material NOT SPECIFIED

Supply Chain

Factory Lead Time 13 Weeks
