0764503108
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Specialized Connector
PDF
/
Inventory: 4635
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material NOT SPECIFIED
Mounting Type Board Edge, Through Hole, Right Angle
Insulation Material THERMOPLASTIC
Mounting Option 1 GUIDE PIN
Mounting Option 2 LOCKING
Technical
Operating Temperature -55°C~85°C
Packaging Tray
Series Impact 76450
Feature Board Guide
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Header, Male Pins
Number of Positions 60
Color Black
Number of Rows 6
Voltage - Rated 30V
Subcategory Headers and Edge Type Connectors
Pitch 0.053 1.35mm
Total Number of Contacts 60
Number of Positions Loaded All
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Rated Current (Signal) 0.75A
Dielectric Withstanding Voltage 500VAC V
Connector Style Impact, Guide Left
Durability 200 Cycles
Withdrawl Force-Min .14734 N
Contact Layout, Typical 20 Differential Pairs
Number of Columns 10
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length - Termination 0.047 inch
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
