0761657606
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Impact 76165 ROHS3Compliant Vertical GENERAL PURPOSE Connector Header, Male Pins UL94V-0 -55C~85C 30V 16.7mm
PDF
/
Inventory: 9221
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 30.4mm
Technical
Number of Columns 16
Contact Layout, Typical 48 Differential Pairs
Connector Style Impact, Guide Left
Max Voltage Rating (AC) 30V
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 144
Contact Finish Gold
Number of Positions Loaded All
Depth 16.7mm
Orientation Vertical
Pitch 0.053 1.35mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature IMPACT, POLARIZED
Number of Rows 9
Color Black
Number of Positions 144
Connector Type Header, Male Pins
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Impact 76165
Packaging Tray
Operating Temperature -55°C~85°C
Physical
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 15 Weeks
