0761655607
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Impact 76165 ROHS3Compliant Vertical GENERAL PURPOSE Connector Header, Male Pins UL94V-0 10mOhm -55C~85C 30V
PDF
/
Inventory: 970
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material NOT SPECIFIED
Contact Plating Gold, Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polymer
Technical
Operating Temperature -55°C~85°C
Packaging Tray
Series Impact 76165
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Header, Male Pins
Number of Positions 144
Color Black
Number of Rows 9
Additional Feature IMPACT, POLARIZED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.053 1.35mm
Total Number of Contacts 144
Orientation Vertical
Depth 16.7mm
Number of Positions Loaded All
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Resistance 10mOhm
Max Voltage Rating (AC) 30V
Connector Style Impact, Guide Right
Contact Layout, Typical 48 Differential Pairs
Number of Columns 16
Dimensions
Length 36.9mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
