0761653803
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Impact 76165 ROHS3Compliant Vertical GENERAL PURPOSE Connector Header, Male Pins UL94V-0 -55C~85C 30V 16.7mm
PDF
/
Inventory: 5771
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Contact Material NOT SPECIFIED
Contact Plating Gold, Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
Technical
Operating Temperature -55°C~85°C
Packaging Tray
Series Impact 76165
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Header, Male Pins
Number of Positions 72
Color Black
Number of Rows 9
Additional Feature IMPACT, POLARIZED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.053 1.35mm
Total Number of Contacts 72
Orientation Vertical
Depth 16.7mm
Number of Positions Loaded All
Number of Columns 8
Contact Layout, Typical 24 Differential Pairs
Connector Style Impact, Guide Left
Max Voltage Rating (AC) 30V
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Reach Compliance Code unknown
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 15.1mm
