0761651635
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Impact 76165 ROHS3Compliant Vertical Male Connector Header, Male Pins UL94V-0 10mOhm 85C 30V
PDF
/
Inventory: 1403
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Contact Plating Gold, Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polymer
Technical
Operating Temperature -55°C~85°C
Packaging Tray
Series Impact 76165
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Header, Male Pins
Number of Positions 144
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Color Black
Number of Rows 9
Gender Male
Voltage - Rated 30V
Pitch 0.053 1.35mm
Orientation Vertical
Depth 16.7mm
Number of Positions Loaded All
Contact Finish Gold
Housing Color Black
Contact Resistance 10mOhm
Number of Circuits 144
Max Voltage Rating (AC) 30V
Connector Style Impact
Contact Layout, Typical 48 Differential Pairs
Number of Columns 16
Dimensions
Length 31.7mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
