0761551636
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
High Speed / Modular Connectors Impact BP 4x16 RW Sn Impact BP 4x16 RW Sn
PDF
/
Inventory: 4991
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 31.7mm
Technical
Number of Columns 16
Contact Layout, Typical 64 Differential Pairs
Connector Style Impact
Max Voltage Rating (AC) 30V
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Reach Compliance Code unknown
Number of Positions Loaded All
Depth 20.8mm
Orientation Vertical
Total Number of Contacts 192
Pitch 0.053 1.35mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 12
Color Black
Number of Positions 192
Connector Type Header, Male Pins
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Impact 76155
Packaging Tray
Operating Temperature -55°C~85°C
Physical
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 11 Weeks
