0761551136
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Conn Hard Metric HDR 120 POS 1.9mm Press Fit ST Thru-Hole Impact? Tray
PDF
/
Inventory: 9900
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
Length 20.3mm
Technical
Number of Columns 10
Contact Layout, Typical 40 Differential Pairs
Withdrawl Force-Min .14734 N
Insertion Force-Max .3336 N
Durability 200 Cycles
Connector Style Impact
Dielectric Withstanding Voltage 500VAC V
Max Voltage Rating (AC) 30V
Rated Current (Signal) 0.75A
Number Of PCB Rows 12
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Number of Positions Loaded All
Depth 20.8mm
Orientation Vertical
Total Number of Contacts 120
Pitch 0.053 1.35mm
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Gender Male
Number of Rows 12
Color Black
Number of Positions 120
Connector Type Header, Male Pins
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Impact 76155
Packaging Tray
Operating Temperature -55°C~85°C
Physical
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 15 Weeks
