0761551103
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Specialized Connector
PDF
/
Inventory: 7028
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material NOT SPECIFIED
Mounting Type Through Hole
Insulation Material THERMOPLASTIC
Mounting Option 1 LOCKING
Technical
Operating Temperature -55°C~85°C
Packaging Tray
Series Impact 76155
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type Header, Male Pins
Number of Positions 120
Color Black
Number of Rows 12
Voltage - Rated 30V
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Pitch 0.053 1.35mm
Total Number of Contacts 120
Number of Positions Loaded All
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Rated Current (Signal) 0.75A
Dielectric Withstanding Voltage 500VAC V
Connector Style Impact
Durability 200 Cycles
Contact Pattern RECTANGULAR
Contact Layout, Typical 40 Differential Pairs
Number of Columns 10
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Length - Termination 0.055 inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
