0761505014
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Specialized Connector
PDF
/
Inventory: 3083
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length - Termination 0.039 inch
Contact Finish Thickness 30.0μin 0.76μm
Technical
Number of Columns 14
Contact Layout, Typical 84 Differential Pairs
Durability 200 Cycles
Connector Style Impact, Guide Right
Insulation Resistance 1000000000Ohm
Contact Resistance 10mOhm
Rated Current (Signal) 0.75A
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Number of Positions Loaded All
Total Number of Contacts 252
Pitch 0.053 1.35mm
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Voltage - Rated 30V
Number of Rows 18
Color Black
Number of Positions 252
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Impact 76150
Packaging Tray
Operating Temperature -55°C~85°C
Physical
Mounting Option 1 LOCKING
Insulation Material THERMOPLASTIC
Mounting Type Board Edge, Through Hole, Right Angle
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 14 Weeks
